Mean Well 1050mA IP67 Constant Current Power Supply | 65W – Dim-to-off


HVGC-65-1050B is a 65W LED AC/DC LED power supply featuring the constant current mode and high voltage output. HVGC-65-1050B operates from 180-528VAC and offers models with a rated current of 350mA and 1050mA. Thanks to the high efficiency up to 90.5%, with the fanless design, the entire series is able to operate for -40°C~+80°C case temperature under free air convection. The design of metal housing and IP65 ingress protection level allows this series to fit both indoor and outdoor applications. HVGC-65-1050B is equipped with Dim-to-off (0-10V, 10V PWM signal and resistive), so as to provide the optimal design flexibility for LED lighting system.

  • Wide input range 180~ 528VAC
  • Constant Current mode output
  • Metal housing with Class I design
  • Built-in active PFC function
  • IP67 design for indoor or outdoor installations
  • Dim-to-off (0-10V, 10V PWM signal and resistive)
  • Typical lifetime>50000 hours
  • 5 years warranty
