Name: Euro Step Light Solid Eyelid
SKU: ESLS/L

Lumen Output*	420 lumens @ 700mA (4 Watts) 240 lumens @ 350mA (2 Watts)
Lumens Per Watt (lm/W)* *Delivered from the Luminaire with an unobstructed beam.	105 lm/W
Power Options	700mA CC Input – Series Wired 6Vf 4.2W 12VAC Input 350mA – Parallel Wired 2.1W 12VAC Input 700mA – Parallel Wired 4.2W 24VDC Input – Parallel Wired 4.2W
Material Options	316 Stainless Steel Solid Copper
Colour Temperature Options	2700K 3000K 4000K
Lens Options	with Clear Lens and Hex Cell Louvre (Standard) with Frosted Lens
Mounting Options	Euro Canister – Aluminium Euro Deck Canister – Aluminium
LED	Cree® XHP-50-2 Plug and Play field replaceable LED board
LED Life Expectancy	50,000 Hrs @ L70
CRI	90+ Standard
Ingress Protection	IP67
Materials	316 Stainless Steel Solid Copper
Warranty	Excludes third party lamps and power supplies 316 Stainless Steel Components – 10 years Electronics – 5 Years Solid Copper Components – 10 Years
Standards	CE IEC/BS/AS/NZ 60598 UL 2108 UL 1838
Recommended Power Supplies	Constant Current Driver REQUIRED for Series Wired ( CC format ) 24VDC Power Supply REQUIRED for 24VDC Parallel Wired ( CV format ) TRANSFORMER REQUIRED for 12VAC Parallel Wired ( CV format )

Hunza® Euro Step Light Solid Eyelid
