Name: Euro Wall Spot
SKU: EWS/L

Lumen Output*	420 lumens @ 700mA (4 Watts) 240 lumens @ 350mA (2 Watts)
Lumens Per Watt (lm/W)* *Delivered from the Luminaire with an unobstructed beam.	105 lm/W
Power Options	700mA CC Input – Series Wired 6Vf 4.2W 12VAC Input 350mA – Parallel Wired 2.1W 12VAC Input 700mA – Parallel Wired 4.2W 24VDC Input – Parallel Wired 4.2W 120-240 VAC – Integral Retro Driver 4.2W
Material Options	316 Marine Grade Stainless Steel Solid Copper
Beam Angle Options	15 Degree 25 Degree 38 Degree 60 Degree
Colour Temperature Options	2700K 3000K 4000K
Lens Options	with Clear Lens and Hex Cell Louvre (Standard) with Frosted Lens
Knuckle Option	with Adjustable Knuckle (Standard) with Locking Knuckle
LED	Cree® XHP-50-2 Plug and Play field replaceable LED board
LED Life Expectancy	50,000 Hrs
CRI	90+ Standard
Ingress Protection	IP66
Materials	316 Marine Grade Stainless Steel Solid Copper
Warranty	Excludes third party lamps and power supplies 316 Stainless Steel Components – 10 years Electronics – 5 Years Solid Copper Components – 10 Years
Standards	IEC/BS/AS/NZ 60598 UL 1598 UL 2108 UL 1838 CE
Recommended Power Supplies	Constant Current Driver REQUIRED for Series Wired ( CC format ) 24VDC Power Supply REQUIRED for 24VDC Parallel Wired ( CV format ) NO DRIVER REQUIRED for Retro™ ‘R’ ( 120/240V Input ) TRANSFORMER REQUIRED for 12VAC Parallel Wired ( CV format )

Hunza® Euro Wall Spot
