Name: Pagoda Light
SKU: PGL/L

Lumen Output*	510 lumens @ 1050mA (6 Watts) 340 lumens @ 700mA (4 Watts) 160 lumens @ 350mA (2 Watts)
Lumens Per Watt (lm/W)* *Delivered from the Luminaire with an unobstructed beam.	85 lm/W
Power Options	1050mA CC Input – Series Wired 6Vf 12VAC Input 350mA – Parallel Wired 2.1W 12VAC Input 700mA – Parallel Wired 4.2W 24VDC Input – Parallel Wired 4.2W 12VAC Input 1050mA – Parallel Wired 6.3W 120-240 VAC – Integral Retro Driver 4.2W
Material Options	316 Marine Grade Stainless Steel Solid Copper Black Bronze Dark Grey Corten Olive Green Silver Star Arctic White Fine Silver White Birch
Beam Angle Options	360 Degree
Colour Temperature Options	2700K 3000K 4000K
Lens Options	with Clear Lens with Opaque Lens
LED	Cree® XHP-50-2 Plug and Play field replaceable LED board
LED Life Expectancy	50,000 Hrs
CRI	90+ Standard
Ingress Protection	IP66
Materials	316 Marine Grade Stainless Steel Solid Copper Solid Powder Coated Aluminium
Warranty	Excludes third party lamps and power supplies 316 Stainless Steel Components – 10 years Aluminium Components – 5 years Electronics – 5 Years Solid Copper Components – 10 Years
Standards	IEC/BS/AS/NZ 60598 UL 1598 UL 2108 UL 1838 CE
Recommended Power Supplies	Constant Current Driver REQUIRED for Series Wired ( CC format ) NO DRIVER REQUIRED for Retro™ ‘R’ ( 120/240V Input ) TRANSFORMER REQUIRED for 12VAC Parallel Wired ( CV format )

Hunza® Pagoda Light
